1x 6 pin Female Header .1"sp LP.225"ht
Click to enlarge
More images
Click to enlarge
Part #: HWS16313
Unit Price: $0.54
Weight: 0.00130 lbs
- Qty Price
- 1+ $0.54
- 50+ $0.51
- 100+ $0.495
- 300+ $0.48
Purchase
Description
FEMALE HEADER SOCKET 6 PIN
1X6 FEMALE RECEPTACLE
STRAIGHT .1" CENTERLINE
(2.54mm Pin Spacing)
SINGLE ROW MATES WITH
.025" SQUARE POST HEADERS
GOLD PLATED CONTACTS
PCB MOUNT SOLDER TAILS
Low Profile Female Header-Socket
.225" (5.7mm) BODY HEIGHT
1X6 FEMALE RECEPTACLE
STRAIGHT .1" CENTERLINE
(2.54mm Pin Spacing)
SINGLE ROW MATES WITH
.025" SQUARE POST HEADERS
GOLD PLATED CONTACTS
PCB MOUNT SOLDER TAILS
Low Profile Female Header-Socket
.225" (5.7mm) BODY HEIGHT
